Key Features:
- Compatible with 99% of 2-point bore gauges on the market.
- Gives instant readings across the full measuring range.
- Easy to set and zero gauges directly where you work.
- Can function as a full calibration station that meets international standards.
- Quick gauge adjustments using smart, easy-to-use adapters.
- Equipped with motorised movement and so helps you position the tool quickly and easily.
- Ready to use in just a few seconds after switching on.
- Connects via RS232 or Bluetooth to fit into your digital systems.
- Strong electronics made to handle rough industrial environments.
- Made of cast iron with the same thermal behaviour as steel. No issues with temperature changes.
- Can be used for both internal and external measuring instruments.
- Acts like one tool for all diameters. No need for multiple ring gauges.
- Allows in-house calibration, giving you full independence without relying on external labs.
Technical Specifications:
| HS3 | 400 | |
|---|---|---|
| Measuring range (external measurements) | mm (in) | 50 ÷ 460 (2 ÷ 18) |
| Measuring range (internal measurements) | mm (in) | 1 ÷ 410 (0.1 ÷ 16) |
| Maximum permissible errors 1) | µm | 0.7 + L(mm)/1000 |
| Repeatability (2s) 1) | µm | 0.5 |
| Resolution | mm (in) | 0.0001 (.000001) |
| Interfaces | RS232 | |
| Operating temperature | °C | 10 ÷ 40 |
| Storage temperature | °C | -10 ÷ 40 |
| Weight | kg | 65 |
1) Values valid at a temperature of 20±0.2°C and a relative humidity of 50±5%
