Features:
- Quick and precise movement of the measuring carriage.
- Measuring force can be adjusted continuously from ~1N to ~12N.
- Electronic control for easy monitoring and adjustment of force.
- Optical and sound indicators for accurate measuring position feedback.
- Exceptional 0.01 μm resolution for high-precision measurements.
- Fully supports Windows 10 & 11 systems.
- Offers a variety of display options for user convenience.
- Compliant with ISO 9000 standards for quality assurance.
- Integrated with trusted WinDHI software for measurement accuracy and temperature control.
- Optional LW-QMSoft software for gauge management and standards, suitable for laboratory integration.
Technical Specifications:
| HC4 | 500 | 1000 | 1500 | 2000 | 3000 | |
| Measuring range * | mm (in) | 550 (20) | 1050 (40) | 1550 (60) | 2050 (80) | 3050 (120) |
| Max. permissible errors, BMPE 1) | μm | 0.3+L(mm)/2000 | ||||
| Repeatability, RMPE (2s) 1) | μm | 0.1 | ||||
| Maximum resolution | mm | 0.00001 | ||||
| Fixed measuring force | N | 0.3 2,3) / 0.5 2,3) / 1 ÷ 12 3) | ||||
| Max. displacement speed | mm/s | 4000 | ||||
| Operating temperature | °C | +10 ÷ +40 | ||||
| Relative humidity | % | 20 ÷ 80 | ||||
| Weight | kg | 94 | 123 | 152 | 181 | 239 |
* The measuring range depends on the anvils used .
1) Values determined at a temperature of 20 ± 0.2 °C and a relative humidity of 50 ± 5 %.
2) With electronic sensor
3) Force display on the WinDHI software window only
